80mm forged milled compressor wheel vs. stock cast wheel for increased component strength, life cycle, and better aerodynamics
96/88mm turbine wheel
Oil feed/drain port: 1/4NP / STD T6
360° thrust bearing vs. stock 270° thrust bearing enhances durability
Increased operational range up to 650 horsepower
Fits most C15, C16 & 3406E applications with T6 flange manifold, doesn’t fit C15 Acert engine
Manufacturer warranty for 1 year from date of purchase
Description
The upgrade 360° thrust bearing enhances turbocharger’s durability against cycle fatigue and thrust issues encountered on some high-performance applications.
Turbine Housing:
T6 twin-scroll 1.32 A/R Non-Wastegated housing
T6 twin-scroll 1.58 A/R Non-Wastegated housing
T6 twin-scroll 1.45 A/R Non-Wastegated housing
Reference part #: 14969880000 Turbo Model: 410SX, 480
